SPECIFY provides professional solutions for construction projects with a wide range of fire-resistant, insulated, thermal, acoustic, and wind load-resistant spiral doors. Fire-Resistant Steel Spiral Doors, with EI90 and E240 fire resistance ratings, meet high security requirements. You can contact us for specification preparation, technical specifications, and consulting services tailored to your project needs, including different curtain profile options and the right actuator selections.
Applications of Insulated Fire-Resistant Roller Shutters
- In airports, aircraft parking areas, and hangar entrances,
- In large-scale industrial production facilities and commercial buildings,
- In loading stations and cold storage facilities,
- In industrial zones and factory or warehouse areas within large-scale developments,
- In production facilities and buildings with high fire and explosion hazards, such as chemical, pharmaceutical, textile, furniture, wood, and electrical systems,
- In buildings with fire and explosion risks,
- In the automotive industry, vehicle parking areas,
- In buildings with high user traffic, such as schools, hospitals, hotels, shopping malls, and parking garages,
- In all types of buildings, both interior and exterior, requiring acoustic, insulation, radiation shielding, and wind resistance properties.
Advantages of Insulated Fire-Resistant Roller Shutter Doors
- In the event of a fire, insulated and fire-resistant revolving doors act as a structural barrier in full-height openings to compartmentalize the building and prevent the spread of fire. Doors equipped with fire signals from the building’s alarm system can safely open and close at a reliable speed.
- Roller shutter door system is designed to be activated by a signal from the building’s fire and automation systems during a fire. When the signal is received, the door closes, preventing the spread of the fire throughout the building while allowing for the safe evacuation of users.
- In addition to being designed for fire-resistant wide openings, fire-resistant revolving doors ensure safe entry, exit, and access control in large openings under normal usage conditions.
- Insulated and fire-resistant revolving door systems allow investors and business owners to manage both high-security control and energy efficiency. The mineral wool inside insulated revolving doors plays a significant role in maintaining temperature differences between interior and exterior spaces, as well as reducing sound transmission, noise, and dust ingress and egress.
- For building owners and designers who demand the highest level of life and property protection, these doors are a clear and reliable choice for fire safety.
Steel Roller Shutter Door Profile Details
Technical Specifications
- Single-Wall Profiles: Profiles/curtains made from galvanized interlocking roll-formed steel. Single-wall, perforated or non-perforated profiles, 80 mm curved slat or 110 mm flat slat. Sheet thickness ranges from 0.80 mm to 1.20 mm. The profile/curtain allows ventilation (approximately 25% air passage) and/or ensures the required security while providing visibility from behind.
Model No: NS80 / NS80D / NS110 / NS110D - Double-Wall Profiles: Profiles/curtains made from galvanized interlocking roll-formed steel. Double-wall insulated profiles, 100 mm flat slat, 77 mm and 90 mm curved slats, sheet thickness of 2.00 mm, nominal thickness of 18.5 mm and 24 mm. The profile/curtain is filled with rock wool or polyurethane foam to provide excellent thermal and acoustic insulation.
Model No: NS100/PU | NS100/RW | NS77/PU | NS90/PU - Cage Profile: Made from galvanized steel, stainless steel, or aluminum, with a curved diamond-shaped tube profile of 1.00 mm or 1.20 mm thickness, connected with 3.00 mm thick fastening components. The profile/curtain provides maximum visibility, ventilation, and security while ensuring the required safety.
Model No: NS14-NS18 - PCP Profile: A profile/curtain made from polycarbonate (PCP) material, single-wall, with 77 mm flat slats and a nominal thickness of 3.00 mm. It is fully transparent, ultra-light compared to steel profiles. It is unbreakable, corrosion-resistant, fire-retardant, and 100% UV protected. Integrated with a Ø16 2.00 mm aluminum pipe profile. The profile/curtain provides the required safety while offering an aesthetic appearance both day and night.
Model No: NST77
Roller Shutter Door Operator & Activators
The Revolving Door Operator has a working mechanism specifically designed according to the type of revolving door.
- The Revolving Door Operator can be integrated with various activators suitable for project and usage requirements.
- Different control options are available, and it can be activated by integrating with smart building automation systems.
- In the event of a fire, it connects to the fire control panel for controlled closure. It can also be operated in conjunction with the building’s alarm system.
- The operator’s electric drive is 3Ph 380V/50Hz, with an IP54 protection class suitable for both indoor and outdoor use.
- The motor, directly connected to the winding shaft, features thermal motor protection in the curtain windings, and includes upper and lower limit switches for the control and main current circuits.
- In case of a power failure or mechanical malfunction, manual closure is possible via an emergency hand crank or hand chain with a safety contact.
- Various drive torques are available, depending on the curtain weight.
- It requires less maintenance and installation cost compared to alternatives.
